Pre-owned in very good condition, this Studiologic Sledge is a powerful polyphonic synthesiser with an intuitive user interface.

There are some marks, scratches and signs of wear but overall this synth presents well.

Please note, original power cable and box not included.

Keyboard

Touch

Soft, Medium, Hard, Fixed (programmable) (1)

Sound generation

Max Polyphony 24 voices

2 Parts

Modulation

LFO1, LFO2 (phase synchronized), WHEEL (for Mod wheel and Aftertouch)

Adjustable LFOs speed and depth

LFO shapes: sawtooth, square, triangle, sine, sample & hold, ramp

Destinations: OSC1, OSC2, OSC3, PWM / Wave / FM, Volume, Filter Cutoff

Oscillators (OSC1, OSC2, OSC3)

Range from 64' to 1' with semitone and detune controls

Shapes: sawtooth, square, triangle, sine, pulse (with pulse modulation)

OSC1 with 66 original PPG Wavetables + Sample Player (60 Mb internal memory)

FM (Tone generation): OSC2, OSC3 amount control - Oscillator hard sync (OSC2 to OSC3)

Mixer

Volume and On/Off switch for each oscillator

Noise generator: White/Pink - Volume control

Filter & Amplifier

Slope (24/12 db) - lowpass, highpass, bandpass

Resonance up to self oscillation

Adjustable key track and drive

Filter envelope - ADSR with amount control

Amplifier envelope - ADSR with velocity control

Proportional velocity control on Filter and Amplifier sections

Arpeggiator

Latch mode

Syncable to MIDI clock

Direction up, down, alternate

Range up to 10 octaves

Effects / Processing

2 simultaneous effects

FX1: Chorus / Phaser / Flanger

FX2: Reverb / Delay / Reverb + Delay

Features

999 User Programs (+13 Categories)

Fast sound selection via numeric keypad or encoder

Auto Dual Mode - Split/Layer - programmalbe Split pount for each program

Global

Master tune - Transposer - Pitch/Bend range - Pedal functions (volume, mod
wheel, cutoff) - Pot mode (snap/direct) - Display time - Pitch wheel,
hold pedal assign

MIDI

MIDI Channel - Local On/Off - Clock control - Send/Receive controls

Controls / UI

Display 2x16 digits backlit LCD

Pitch wheel

Modulation wheel

35 Pots

3 "chicken head" rotary switches (7 positions)

1 rotary encoder with push function

Master volume control (with panic and anti-thump circuit)

Numeric keypad

Connections

Audio OUT: 2x 6,3 mm mono jack (L+R)

Headphones: 2x 6,3 mm stereo jack

Pedals: Hold, Expression

MIDI: In, Out

USB: USB to Host, MIDI

Power supply

AC IN: 110-240V

Size and weight

Width: 97 cm / 38,2"

Depth: 40,5 cm / 16"

Height: 11 cm / 4,5"
